269609
Wedge FS7
Contact us
Key features

Compatible with First Solar Series 7 TR1. Mounting from underneath the module. Pre-clipped onto module frame, single-step push-in fastening. Anti-theft protection.

Application
Tile, flat & tin roof
Tile, flat & tin roof
Carport & shed roof
Carport & shed roof
Fixed tilt
Fixed tilt
Tracker
Tracker
Assembly configuration

Module types: First Solar Series 7 TR1

Rail type: First Solar Series 7 TR1

Module mount layout: H/V

Certifications
UL 2703 UL 2703
Downloads
Dimensions
Tech specs (mm)
B1 - Width of Hole
7.2 - 7.4
L1 - Length of Hole
27.2
Material
Hardened Carbon Steel
Coating
Zinc Iron Alloy Thermal Diffusion Coating
Installation tool
Mallet, install bit and hammer drill ARaymond 50564723
